ASUS XONAR DG Headphone Amp & PCI 5.1 Audio Card

ASUS XONAR DG Headphone Amp & PCI 5.1 Audio Card

by Asus

Availability: In stock. Usually ships within 2 to 3 days.

$108.86

* Price as of 2022-10-04 22:44 CET -

Share This Page

Product Features

Audio Performance: Output Signal-to-Noise Ratio (A-Weighted): 105 dB; Input Signal-to-Noise Ratio (A-Weighted):
Frequency Response (-3dB, 24-bit/96kHz input): <10Hz to 48KHz; Output/Input Full-Scale Voltage: 1 Vrms (3 Vp-p);
Audio Processor: C-Media CMI8786 High-Definition Sound Processor (Max. 96KHz/24bit); 24-bit D-A Converter of Digital Sources: 1x Cirrus-Logic
24-bit A-D Converter for Analog Inputs: 1x Cirrus Logic CS4245 (104dB DNR, Max. 192KHz/24bit);
Analog Recording Sample Rate and Resolution: 44.1K/48K/96KHz @ 16/24bit; S/PDIF
Digital S/PDIF Output: High-bandwidth Optical Connector supports 96KHz/24bit, additional SPDIF-out header for HDMI audio output;
I/O Ports: Analog Output Jack: 3x 3.50mm mini jack(Front/Side/Center-Subwoofer);
Operation System: Windows 7/Vista/XP/MCE2005; Accessories: 1x Low-profile Bracket; 1x Driver CD; 1x Quick Start Guide
103 dB; Output THD+N at 1kHz: 0.0025% (-92dB); Input THD+N at 1kHz: 0.0022% (-93dB)
Analog Input Jack: 1x 3.50mm mini jack(Line-In/Mic-In); Other line-level analog input (for CD-IN/TV Tuner): Aux-In (4-pin header on the card)
Front-Panel Header: Supports headphone jack-detection, automatically switch audio output from back-panel to front
Digital Output: 44.1K/48K/96KHz @ 16/24bit, Dolby Digital, DTS, WMA-Pro; ASIO 2.0 Driver Support: 44.1K/48K/96KHz @ 16/24bit
High Fidelity Headphone Amplifier: Optimized for 32~150Ω; Analog Playback Sample Rate
Resolution: 44.1K/48K/96KHz @ 16/24bit for all channels
CS4245 (104dB DNR, Max. 192KHz/24bit), 1x Cirrus-Logic CS4361(103dB DNR, Max. 192KHz/24bit)
Bus Compatibility: PCI v2.2 or above bus compatible

Product Details

Brand	Asus
SKU	B003ZXDOL6
Model	XONAR_DG
MPN	XONAR_DG
EAN	0012300364508 0088020585745 5053973133751 5054533632622 4719543330692 0803982784568 1320010243914 0763616035025 0610839339976 5054484632627 4719543339978 0132017945682 0115970737334 0012305075317 5147841728955 5053313230096 0016839339976 5054230210796
UPC	012305075317 803982784568 763616035025 016839339976 088020585745 132017945682 115970737334 610839339976 012300364508
